Application purposes
- For renovations, conversions and new buildings
- For replacing low-level exposed cisterns
- For replacing wall-hung WCs with close-coupled exposed cistern
- For Geberit AquaClean WC complete solutions
- For mounting on finished floors
- For installation in front of drywalls or solid walls
- Dual flush
- Front cladding made of glass (ESG)
- Fastening height WC ceramic appliance 35 ± 1 cm
- Cistern fully insulated against condensation
- Side cladding made of aluminium brushed
- Self-supporting
- Adjustable flush volume
- Soft-touch buttons for flush actuation and odour extraction
- Orientation light and odour extraction activated when a user approaches
- Orientation light can be set in seven colours
- Day/night detection can be set for orientation light
- Odour extraction unit automatically switches off after a predefined running time
- Water supply connection set with 2 angle stop valves, 1/2"
- Flush bend extension 160 mm
- Sleeve made of EPDM, ø 44 / 55 mm
- Straight connector made of PE-HD, ø 90 mm
- Adapter socket made of PE-HD, ø 90 / 110 mm
- 2 threaded rods M12
- Sound insulation set
- Female socket for mains connection
- Power supply unit
- Fastening material
131.221.SI.5 | glass/white | |
Protection class | I | |
Protection degree | IPX4 | |
Nominal voltage | 100-240 | V AC |
Operating voltage | 4.1 | V AC |
Mains frequency | 50-60 | Hz |
Power consumption | 5 | W |
Flow pressure | 0.1-10 | l |
Flush volume factory settings | 6 and 3 | l |
Flush volume, large | 4.5/6/7.5 | l |
Flush volume small | 3-4 | l |
