Geberit urinal flush control with pneumatic flush actuation, actuator plate type 50

116.016.xx.1

Geberit urinal flush control with pneumatic flush actuation, actuator plate type 50

Ask for a price: 02 / 968 11 11
Application purposes
  • For manual flush actuation of urinals
Scope of delivery
  • Actuator plate type 50
  • Pneumatic flush actuation, premounted on mounting frame
  • Pneumatic valve
  • Fastening material
116.016.00.5 customised die cast zinc
116.016.11.5 white alpine die cast zinc / plastic
116.016.DW.5 jet black RAL 9005 die cast zinc / plastic
116.016.GH.5 brushed chrome die cast zinc
116.016.SD.5 smoked glass reflective die cast zinc / glass
116.016.SQ.5 umber die cast zinc / glass
Flow rate at 1 bar without flow limiter 0.3 l/s
Flow rate at 1 bar with flow limiter 0.24 l/s
Flush time, adjustment range 4/8/12 l/s
